Cat 5e S/FTP Cable:

Basic Parameters

Cable Feature: These Cat5e S/FTP cables are manufactured in accordance with IEC 61156-5 requirements, can support all Class D applications like Ethernet, Fast Ethernet, Gigabit Ethernet, suitable for basic voice and data installations up to 100MHz.

Bending Radius: 8×OD (during installation); 4×OD (fixed installed)

Temperature Range: -40℃ ~ +85℃

Standards

EN 50173-1, EN 50288-2-1, ISO/IEC 11801, IEC 61156-5 , IEC 60332-3-24, IEC 60754-1/2 ,IEC 61034-1/2.

Construction

Conductors: Stranded copper conductor.

Insulation: PE.

Twinning: Two coloured insulated conductors twisted together to form a pair.

Individual Screen: Al/polyester tape.

Overall Screen: Tinned copper wire braid.

Outer Sheath: Oil resistant, flame retardant and halogen free LSOH (SHF1).
